Graphene On Ultra-Fine, 2000 Cu, 3-5 Layers
CAS No. 7782-42-5
Characteristics
- Four thicknesses of CVD graphene
- Available in either 1, 2, 3-5 or 6-8 layers
- TEM Substrate
- Microporous Copper TEM Grids with Beryllium-Copper Support Aperture
- Graphene coverage of the TEM grid is better than 75%
Appearance
The graphene film appears as a near-transparent to light-grey film on the surface of the red-brown microporous copper TEM grid. For support, the TEM grid is attached using epoxy to a gold-colored beryllium-copper disk with a 2 x 1 mm aperture.
Specifications
Type |
Thickness of the Graphene |
Transparency |
TEM Grid/AFM Substrate |
Support Film |
3-5 Layers |
1.0-1.7 nm |
~85.8-90.4% |
2000 Mesh Copper Grid |
N/A |
SKU:
3GUF2000Cu-25
Pack:
25 Pack
