Graphene On Ultra-Flat Thermal SiO2, 2 Layers


  1. Four thicknesses of CVD graphene
    • Available in either 1, 2, 3-5 or 6-8 layers
  2. TEM Substrate
    • The Ultra-flat Thermal SiO2 Substrate consists of a 200 nm thermally grown SiO2 film on an ultra-flat silicon wafer with a normal thickness of 675 µm. The size is 5 mm x 5 mm.
  3. Graphene coverage of the TEM grid is better than 75%


Type Thickness of the Graphene Transparency TEM Grid/AFM Substrate Support Film
2 Layers ~0.7 nm ~92.7% Ultra-Flat Silicon Thermally Grown SiO2
Pack: 5 Pack
