300 DPI resolution — ideal for fine detail text and barcodes.
Print small text and crisp barcodes with ease. Powered by Label LIVE design and print software (included) that works on both Windows and macOS. Plug-and-print functionality without installing drivers. Import spreadsheet data and print batches of unique barcoded labels. Label designs can be saved for future use and shared with others. The myDPI300v1 features multiple adjustable sensors that allow for compatibility with a wide variety of direct thermal labels, including Direct Thermal Cryo-Tags®.
Features
- Adjustable label sensor for off-center holes, gaps, and black line labels
- Use labels as narrow as 0.79" (20mm) wide
- Full-size print width of 4" (102mm) with 4.6875" maximum media width
- Traditional internal label roll holder with 4.25" (108mm) diameter capacity
Requirements
Use with Label LIVE design software (included), no drivers required. Prints one color: black. Requires direct thermal labels or tags. USB-only, no wireless, no Bluetooth. Works with Windows 10/11 and macOS, (not iOS, not Android, not Chromebook).
Operating Environment
| |
| Specifications |
| Media |
| Direct Thermal |
Continuous, gap, black mark |
| Width |
0.78" – 4.6" (20mm – 118mm |
| Length |
0.39" – 70" (10mm – 1778mm) |
| Thickness |
2.36 mil – 9.8 mil (.06mm – 0.25mm) |
| Inner Diameter Core |
1" to 3" (25.4mm to 76.2mm) |
| Outer Diameter |
5" (127mm) |
| Temperature |
41°F – 104°F (5°C – 40°C) |
| Humidity |
25% – 85% non-condensing |
| Storage |
| Temperature |
-40°F – 140°F (-40°C – 60°C) |
| Humidity |
10% – 90% non-condensing |
| Software |
| Label LIVE |
Windows 10 or newer, macOS |
| Optional Drivers |
Windows, macOS |
| External |
| Interface |
USB 2.0 |
| Width |
7.47" (189.62mm) |
| Height |
7.03" (178.5mm |
| Depth |
8.62" (219.03mm) |
| Weigth |
3.48 lb (1.58 kg) |
| Power |
| Input |
AC 100~240V |
| Output |
DC 24V, 2.5A, 60W |
| |
|
