The NUNC™ Coverglass Optical Bottom 384 Well®️ Plates have the same quality design of existing NUNC™️ well products, plus an optically clear polystyrene plate bottom. This clear base permits microscopic viewing and reading of well
The plate's upper structure is offered in black (for fluorometric detection)
384 Well® Optical Bottom Plates – Polymer Base
- Black upper structure with optical clear polystyrene bottom
- Can be read from top or bottom
- Rounded square wells eliminate wicking
- Optimized for scintillation counting
- Cell Culture, Collagen I or Poly-D-Lysine surfaces for cell-based arrays
- Non-treated surface for homogeneous assays
- Working range: 10-100 µl/well
| H1 Plate total height |
14.4 mm |
| H2 Vertical distance from inside well bottom to resting plane |
2.7 mm |
| H3 Inside depth of well |
11.6 mm |
| H4 Polystyrene film |
2.5 mm |
| H5 Height of flange |
2.7 mm |
| H7 Bottom Thickness |
0.3 mm |
| D1 Well diameter, top |
3.7 x 3.7 mm |
| D2 Well distance bottom |
2.9 x 2.9 mm |
| F1 Depth of flange |
1.8 mm |
| F1 Depth of flange |
1.8 mm |
External plate dimension 128 x 86 mm
| NUNC # |
Description |
Color |
Sterile |
Lid |
| 152041 |
Collagen I |
Black |
no |
yes |
